Description
The ME Series Inverter / Charger from Magnum Energy is a modified sine wave inverter designed specifically for rugged mobile applications.
Specifications
| dimensions |
13.75″H x 12.65″W x 8.0″D (34.9 cm x 32.1 cm x 20.3 cm) |
| input current |
Maximum: 266 ADC |
| input voltage range |
9 – 16 VDC |
| max operating altitude |
15,000 (4570 m) |
| nominal ac output voltage |
120 VAC – 5% |
| nonoperating temperature |
-40 degrees C to +70 degrees C (-40 degrees F to 158 degrees F) |
| no load |
(120 VAC output, typical): 20 watts |
| operating humidity |
0 to 95% RH non condensing |
| operating temperature |
-20 degrees C to +60 degrees C (-4 degrees F to 140 degrees F) |
| output frequency and accuracy |
60 Hz – 0.1 Hz |
| transfer relay rating |
2 legs at 30 A for 120 V/30 A or 240 V/60 A service |
| waveform |
Modified Sine Wave |
